High Vacuum Furnace Vacuum Equipment

General description:

C 500 Series
The C 500 is a series of furnaces specially designed and developed for high vacuum degassing of mechanical components or materials that require this procedure and which
C 750 Series
The C 750 is a series of furnaces specially designed and developed for main low-temperature heat treatments in high vacuum conditions. These furnaces are particularly well suited to inert gas convection treatments after vacuum purge such as: tempering, annealing, stress relieving customized for specific application needs.

C 500 Main technical parameters:

- Vacuum level 5x10-6 mbar with vacuum oil diffusion pump
- Degassing temperature - maximum 500 C
- Homogenity of +/ -5 over 250 - 450 C range
- Cooling - naturally, up to 10 mbar (or other pressure settable) after the furnace is pressurized - cooling speed is limited by the thermal inertia of the oven
- Injection of inert gases, cooled and recirculated - recommended at temperatures below 150 C

C 500 Main technical parameters:

- Vacuum level 5x10-6 mbar with vacuum oil diffusion pump
- Degassing temperature - maximum 750 C
- Homogenity of +/ -5 over 250 - 650 C range
- Inert gas cooling, pressure mas 1.2 bara

Detalils on High Vacuum Furnace (PDF file)
